Parameter | Specification |
Process Connection | Flange |
Frequency Range | 76~81GHz |
Transmission Angle | 3° |
Measuring Range | 120m |
Housing Material | Aluminum Cast/Stainless Steel |
Power Supply Range | 18-28VDC |
Output Signal | 4~20mA/HART (2-wire/4-wire), RS485/Modbus |
Medium Temperature | -30~1000°C |
Process Pressure | -0.5~3MPa |
Measuring Accuracy | ±1mm |
Protection Grade | IP68 |
Explosion-Proof Grade | EX d ia IIC T6 Gb |
Bluetooth | Optional |
Application Range | Various high temperature and high pressure environments (solids, liquids) |
